HS1106 Hot Melt Applicator

UP
HS1106
English

FEATURES

  1. The melting tank increases the area for spreading heat and improve the melting rate.
  2. Applicator temperature is exactly controlled by electronic P.I.D numeric controller to avoid carbonization inside the tank.
  3. Lined with double temperature control inside to better protect security.
  4. Modularizing design helps to change various size gear pump or handle the return valve easily.
  5. Apply to automatic packaging, shoes-making and life paper.

SPECIFICATIONS

SPEC UNIT HS1106
Tank Capacity Liter 10
Max. Melting Rate Kg/HR 10
Max. Operation Temperature °C 200
Max. Viscosity CPS 30,000
Sets of Hose and Gun Set 1~2
Max. Glue Flow Rate g/Min 400
Dimensions mm 675 × 580 × 471
Weight Kg 65
Melting Tank Power Watt 3000
Power Requirement   220V AC,18A,50/60Hz,1Φ
